UV Master Technology
Highly concentrated UV radiations.
Easy To Handle
Spacious UV exposure chamber in stainless steel.
Long Lifetime
Protective quartz disk on the UV sensor cell.
Ondulex Reflector
Reflect the maximum UV output.
The Bio-Link is a UVA, UVC or UVB irradiation system, mainly dedicated to the binding of nucleic acid to membranes and the removal of contamination by PCR. Its innovative design gives it unique characteristics:
- Microprocessor controlled. The programmable microprocessor permanently controls the UV light emission. Irradiation stops automatically when the received energy corresponds to the programmed energy.
- Reproducibility. Thanks to its UV sensor, the irradiation cycles are perfectly reproducible, regardless of the fluctuation in the intensity of the UV source. Simply program your energy and Bio-Link delivers it!
- Consistent measure. The UV light sensor is placed above a well of light at the top of the irradiation chamber. The UV measurement is then collected in all the UV tubes and not just in one, for better consistency!
- Ease of use. The large number of presets in units of energy or time makes the Bio-Link a very simple to use yet powerful instrument.
- Durability. The Bio-Link combines the latest technology with the highest quality components: UV exposure chamber made of stainless steel, quartz protection disc on the UV sensor cell, highly resistant touch membrane keypad, …
KEY FEATURES
- Precise irradiation in energy (Joules/cm2) or time (seconds)
- Preset program for 0.120 J/cm2 to optimize nucleic acid binding
- Storage of the last UV setting
- Protective quartz disc on the UV sensor cell
- Spacious stainless steel UV exposure chamber
- Safety locking door with UV blocking observation window
- Interchangeable UV wavelengths
Table Of Products
Our large choice of filter and unfiltered lamps range from 6 to 3×40 w-watt. Our filtered lamps are ideal for the fluorescence detection. The BL-Black-Light lamps provides a large light spectrum with 365nm UV and visible light. The UV germicidal 254nm lamps help to prevents contamination in research laboratories.
Table Of Products
Our large choice of filter and unfiltered lamps range from 6 to 3×40 w-watt. Our filtered lamps are ideal for the fluorescence detection. The BL-Black-Light lamps provides a large light spectrum with 365nm UV and visible light. The UV germicidal 254nm lamps help to prevents contamination in research laboratories.
| UV Source | 5 x 8-watt Either in 254nm (UV-C), 312nm (UV-B), 365nm (UV-A) |
| Energy Diplay |
Two measurement ranges:
|
| Expsure Time Display |
Two measurement ranges:
|
| Manual Control | Manual energy exposure adjustment Manual exposure time adjustment |
| Presets | Energy: 9 presets Exposure time: 9 presets |
